160 Tray Wood Fire Rotary Oven

Product Description

160 Tray Wood Fire Rotary Oven Specification

1. Capacity

• 160 trays standard size 13 x 18 inches or 400 x 600 mm

• Suitable for large scale baking like bread buns and cakes

2. Heat Source

• Wood fired combustion chamber

• Even heat distribution

• Natural wood aroma for better flavor

3. Construction

• Double wall insulated stainless steel body

• Inner chamber made of SS 304 grade

• Outer frame in powder coated or stainless steel

4. Rotation System

• Rotary rack system

• Heavy duty motorized rotation for uniform baking

• Easy loading and unloading

5. Temperature Control

• Thermostat controlled up to 300 degree Celsius

• Analog or digital temperature display

• Manual damper for smoke and heat control

6. Baking Time

• Adjustable timer from 0 to 60 minutes

• Alarm when cycle completes

7. Fuel Consumption

• Approximately 15 to 25 kg wood per batch

• Depends on usage and wood type

8. Safety Features

• Heat resistant door handle

• Glass window for viewing

• Overheat protection

9. Dimensions Approximate

• Length 2200 mm Width 2000 mm Height 2600 mm

• Tray space supports 160 trays with 100 mm gap

10. Power Supply for Controls

• 220 Volt single phase 50 Hertz used for rotation and display only
